PORTABLE METAL SAWING MACHINES

The portable metal sawing machines described in this section are those lightweight and easily transportable saws that are used in a field or normal machine shop by maintenance personnel. These saws can be used to cut stock that is too big or too long to move to a maintenance shop to be cut. The following portable sawing machines are described in this section: the portable hacksawing machine, the portable band sawing machine, and the portable reciprocating saw. Two of these saws are operated by hand, so the quality of work depends upon the experience and skill of the operator. Portable metal sawing machines can be used in the maintenance shop to cut wood, steel, plastics, electrical conduit, tubing, pipes, and shop stock, and for auto body work.

THE PORTABLE HACKSAWING MACHINE

The portable hacksawing machine (Figure 1) is not designed to be hand-held, but to lock onto the workpiece with a self-contained vise. This saw has a built-in electric motor that causes a power hacksaw blade to reciprocate at a fixed speed of 115 strokes per minute. The machine is capable of cutting solid steel 3 inches square and at an angle to 45°. This saw can be used in a horizontal, angular, or vertical position, having an adjustable counterbalance to compensate for operating the sawing machine in a vertical position. A 10-inch power hacksaw blade is used with this machine, producing a 4-inch stroke. A tension screw permits increasing or decreasing the blade pressure with each cut. The portable hacksawing machine will support itself when fastened very securely to a stationary workpiece, using the self-contained vise.



To operate the portable hacksawing machine, insert a power hacksaw blade of 18, 24, or 32 teeth per inch, depending on the material to be cut. Then, check the adjustment of the tension screw and the adjustment of the counterbalance lever. Turning the tension screw clockwise will increase the amount of lift the hacksaw blade makes on each return stroke and will increase the downward pressure of the blade on each cutting stroke. Counterclockwise rotation of the screw will decrease the lift and pressure. This control should be adjusted to cause the hacksaw blade to lift 1/8 inch on each return stroke to provide maximum cutting speed and efficiency. The counter balance lever controls the downward pressure exerted upon the hacksaw blade by the weight of the saw frame. By moving the counterbalance lever to the left, the pressure is decreased. Moving the lever to the right increases the pressure. Mount the workpiece squarely or angularly in the vise, depending on the type of cut desired. Start the sawing machine and observe the cutting action. If the machine strains, the blade pressure may be too heavy.

If the machine cuts very slowly, increase the pressure.

Continuously check the power hacksaw blade for sharpness. If the blade is dull, it should be replaced. When the machine cuts completely through the material, the saw frame will fall and trip the motor switch, stopping the saw.

When the sawing machine is used in the vertical position, the counterbalance lever must be positioned in the farthest right notch of the guide bar ratchet to compensate for the lack of gravitational pressure normally applied to the blade by the saw frame. This practice should be attempted only if the workpiece can be clamped very securely in the vise and cannot be wrenched loose during vertical sawing, or damage to personnel or equipment could occur.

SIERRAS DE METAL PORTÁTILES

Las sierras de metal portátiles descritas en esta sección son aquellas sierras de poco peso y fácilmente transportables que son utilizadas en campo o un taller de máquinas o de uso normal por el personal de mantenimiento. Estas sierras se pueden utilizar para cortar material que es demasiado grande o demasiado largo moverse al taller de mantenimiento para su corte. Las sierras portátiles siguientes se describen en esta sección: la sierra alternativa portátil para metal, la sierra portátil de cinta, y la sierra recíproca portátil. Dos de estas sierras se operan a mano, así que la calidad del trabajo depende de la experiencia y la habilidad del operador. Las sierras de metal portátiles se pueden utilizar en el taller de mantenimiento para cortar madera, acero, plásticos, conductos eléctricos, tuberías, cañerías, mercancía en almacén, y para trabajos de carrocerías de automóviles.

LA SIERRA CORTAMETALES PORTÁTIL

La sierra para metales portátil (figura 1) no está diseñada para ser operada a mano, sino para ser fijada sobre el objeto de trabajo con un tornillo de banco adjunto. Esta sierra viene con un motor eléctrico incorporado que hace que una resistente lámina de sierra para metales se mueva en forma alternativa a una velocidad fija de 115 movimientos por minuto. La máquina es capaz de cortar acero sólido de 3 pulgadas cuadradas y en ángulos de 45°. Esta sierra puede ser utilizada en una posición horizontal, angular, o vertical, teniendo un contrapeso ajustable para compensar el funcionamiento de la sierra en una posición vertical. Una lámina de sierra eléctrica para metales de 10 pulgadas se utiliza con esta máquina, produciendo un movimiento de 4 pulgadas. Un tornillo de tensión permite aumentar o disminuir la presión de la lámina con cada corte. Esta máquina de corte portátil se soportará a sí misma cuando está sujeta en forma segura a un objeto de trabajo inmóvil, usando el tornillo de banco o morsa adjunto.

Para hacer funcionar la máquina portátil de corte de metales, inserte una hoja de sierra de máquina para metales de 18, 24, o 32 dientes por pulgada, dependiendo del material que se cortará. Luego, compruebe el ajuste del tornillo de tensión y el ajuste de la palanca de contrapeso. Al girar el tornillo de tensión en sentido horario aumentará la cantidad de elevación que la hoja la sierra para metales hace en cada movimiento de vuelta y aumentará la presión hacia abajo de la hoja en cada movimiento de corte. La rotación en sentido anti horario del tornillo disminuirá la elevación y la presión. Este control se debe ajustar para hacer que la hoja de la sierra para metales se levante 1/8 pulgada en cada movimiento de vuelta para proporcionar velocidad y eficacia máximas de corte. La palanca de contrapeso controla la presión de bajada ejercida sobre la hoja de sierra para metales por el peso del bastidor de sierra. Moviendo la palanca de contrapeso a la izquierda, se disminuye la presión. Al mover la palanca a la derecha, se aumenta la presión. Coloque el objeto en ángulo recto o angular en el tornillo de morsa, dependiendo del tipo de corte deseado. Encienda la sierra y observe el movimiento de cizallamiento. Si la máquina trabaja forzada, la presión de la hoja puede ser demasiado pesada.

Si la máquina corta muy lentamente, aumenta la presión.

Compruebe continuamente el filo de la hoja de sierra para metales. Si la hoja está gastada, debe ser substituida. Cuando la máquina finaliza el corte de todo el material, el marco de sierra caerá y disparará el interruptor del motor, parando la sierra.

Cuando la máquina de aserrar se utiliza en posición vertical, la palanca de contrapeso se debe colocar en la muesca a la derecha más alejada del trinquete de la barra de guía para compensar la falta de presión gravitacional aplicada normalmente a la hoja por el marco de sierra. Esta práctica debe ser intentada solamente si el objeto se puede fijar mediante abrazadera con mucha seguridad en la morsa y que no se pueda aflojar durante el aserrado vertical, o podría producir un daño al personal o al equipo.

Fig. 1 - Portable hacksawing machine - Sierra cortametales portátil

Saw Z All 15Amp Super Sawzall Reciprocating Saw 653821 by Milwaukee

Saw Z All 15Amp Super Sawzall Reciprocating Saw 653821 by Milwaukee

$250.89  $225.40

Reciprocating saw kits 15 amp orbital action vssawzall Variable speed trigger and dial speed control, motor overload protection prevents motor burn up/failure, constant power technology maintains constant speed under load for unmatched cutting performance, 1 1/4 inches stroke length, gear protecting clutch extends gear and motor life by absorbing high impact forces caused by sudden blade lockups, counter balanced mechanism, QuikLok blade clamp system provides fast and easy blade changes. Includes saw and hard case. [Read more]

Brand: Milwaukee

Saw Z All 11 Amp Reciprocating Saw With Case 650922 by Milwaukee

Saw Z All 11 Amp Reciprocating Saw With Case 650922 by Milwaukee

$157.59  $141.40

Used for high performance cutting in a variety of materials. Gear protecting clutch extends gear and motor life by absorbing high impact forces caused by blade lock ups. Counter weighted mechanism provides reduced vibration for smoother operation. QuikLok blade clamp provides fast, tool free blade changes. Specs: 3/4 inch stroke length, no load SPM 03,000, variable speed, 19 inch long, weighs 7.1 pound Includes: saw, carrying case. [Read more]

Brand: Milwaukee

Saw Z All Cross Grit Reciprocating Saw Blade Pack Of 3 48001420 by Milwaukee

Saw Z All Cross Grit Reciprocating Saw Blade Pack Of 3 48001420 by Milwaukee

$18.25  $14.89

Reciprocating saw blades tungsten carbide general cuttingsuper sawzall vinyl pouch grit=coarse Length 6 inch card of 3 Materials, tooth configuration and heat treating are designed to maximize performance in specific cutting applications. Durable, long life blades. Blade has a 1/2 inch universal tang that fits all Sawzalls and standard competitive saws. Applications: Cuts Hardwood Flooring, Cast Iron, Stainless Steel, Fiberglass Materials, (Polyesters, Epoxies, Melamines), Ceramic Tile, Stone, Slate, Clay Pipe, Carbon, Brick, Plaster, Marble, & Chalkboard. [Read more]

Brand: Milwaukee

Saw Z All Reciprocating Saw Blade Kit 12 Piece 49221129 by Milwaukee

Saw Z All Reciprocating Saw Blade Kit 12 Piece 49221129 by Milwaukee

$34.35  $27.20

Reciprocating saw blade demolition set, 12piece. Features Matrix II bimetal teeth for greater durability. Demolition blades are thicker for maximum durability and taller for straighter cuts. Features 12 of Milwaukee's most popular demolition blades. Kit includes 2 of each: No.48005021 5 TPI, 6 inches Length, No.48005026 5 TPI, 9 inches Length, No.48005701 8 TPI, 6 inches Length, No.48005787 14 TPI, 9 inches Length. 4 each: No.48005782 14 TPI, 6 inches Length and a storage case. [Read more]

Brand: Milwaukee

Super Sawzall 6 Inch Reciprocating Saw Blade Pack Of 5 48005091 by Milwaukee

Super Sawzall 6 Inch Reciprocating Saw Blade Pack Of 5 48005091 by Milwaukee

$14.55  $11.99

Reciprocating saw blades bimetal wood/plastic/metal cuttingsuper sawzall vinyl pouch teeth per inch=8/12 Length 6 inch card of 5 Made with Matrix II high speed steel teeth containing 8 percent Cobalt to keep a sharper tooth edge longer. Faster cutting, longer life blades that can bend without shattering. This blade has a 1/2 inch universal tang that fits all Sawzalls and standard competitive saws. Applications: All Woods, Nail Embedded Woods, Composition Material, Plastic, Ferrous & NonFerrous Metals & Cast Iron. [Read more]

Brand: Milwaukee

Super Sawzall 6 Inch Reciprocating Saw Blade Pack Of 5 48005186 by Milwaukee

Super Sawzall 6 Inch Reciprocating Saw Blade Pack Of 5 48005186 by Milwaukee

$14.65  $11.29

Reciprocating saw blades bimetal metal cuttingsuper sawzall vinyl pouch teeth per inch=24 Length 6 inch card of 5 Matrix II high speed steel teeth containing 8 percent Cobalt to keep a sharper tooth edge longer. BiMetal design allows faster cutting, longer life blades that can bend without shattering. 1/2 in. Universal Tang fits all Sawzalls. Applications: Cutting Metal Thinner Than 1/8 in, Tubing, Pipe, & Trim. [Read more]

Brand: Milwaukee

Super Sawzall 6 Inch Reciprocating Saw Blade Pack Of 5 48005184 by Milwaukee

Super Sawzall 6 Inch Reciprocating Saw Blade Pack Of 5 48005184 by Milwaukee

$14.55  $10.80

Reciprocating saw blades bimetal metal cuttingsuper sawzall vinyl pouch teeth per inch=18 Length 6 inch card of 5 Matrix II high speed steel teeth containing 8 percent Cobalt to keep a sharper tooth edge longer. BiMetal design allows faster cutting, longer life blades that can bend without shattering. 1/2 in. Universal Tang fits all Sawzalls. Applications: Cutting metal 1/8 in. thru 3/16 in, Conduit, Tubing, Channels, & Pipe. [Read more]

Brand: Milwaukee

Reciprocating Saw 7.5Amp PC75TRS by Porter Cable

Reciprocating Saw 7.5Amp PC75TRS by Porter Cable

$78.59  $70.30

Reciprocating saws 11/8 inch 7.5 amp vs keyless Twist lock toolfree blade change. Variablespeed trigger maintains speed for multiple cutting tasks. Pivoting shoe easily maneuvers around objects while cutting. Tooled shoe adjustment easily allows depth adjustment and extends blade life. Compact and lightweight design prevents user fatigue. Specs: 120V, 3,200 spm, keyless blade clamp, adjustable shoe, variablespeed trigger, antislip comfort grip, weighs 6.8 lbs. Includes wood cutting blade. [Read more]

Brand: Porter Cable

20-Volt MAX Li-Ion Hammerdrill and Reciprocating Saw Combo Kit DCK292L2 by DeWalt

20-Volt MAX Li-Ion Hammerdrill and Reciprocating Saw Combo Kit DCK292L2 by DeWalt

$490.69  $441.20

Cordless combo kits 2 tools 20 volt Hammerdrill features 3speed allmetal transmission, 0575/01,350/02,000 max rpm, 09,775/022,950/034,000 max bpm, 22 clutch settings, 1/2 inches all metal ratcheting chuck delivers 535UWO. Reciprocating saw features 4position keyless blade clamp, 1 1/8 inches stroke length, variable speed with 03000 spm, pivoting adjustable shoe, rubber over molded comfort grip, double oil sealed shaft, and electric brake. Includes: 2 tools, (2) 20V Max lithium ion 3.0 Ah battery packs, fast charger, 360degree side handle and contractor bag. [Read more]

Brand: Dewalt

Super Sawzall 9 By 3/4 Inch Reciprocating Saw Blade Pack Of 5 48005036 by Milwaukee

Super Sawzall 9 By 3/4 Inch Reciprocating Saw Blade Pack Of 5 48005036 by Milwaukee

$22.89  $17.59

Reciprocating saw blades bimetal wood cuttingsuper sawzall vinyl pouch teeth per inch=6 Length 9 inch card of 5 Made with Matrix II high speed steel teeth containing 8 percent Cobalt to keep a sharper tooth edge longer. Faster cutting, longer life blades that can bend without shattering. This blade has a 1/2 inch universal tang that fits all Sawzalls and standard competitive saws. Applications: Nail Embedded Wood & General RoughingIn Work. [Read more]

Brand: Milwaukee

Tuff Tooth 10 Tooth Reciprocating Saw Blade Pack Of 5 20562 610R by Lenox Tools

Tuff Tooth 10 Tooth Reciprocating Saw Blade Pack Of 5 20562 610R by Lenox Tools

$17.39  $13.10

Reciprocating saw blades wood/plastic/metal cutting rentaltuff tooth carded teeth per inch=10 Length 6 inch card of 5 Optimized for specific application. Shatter resistant, bimetal design provides the flexibility and durability singlemetal blades can't. Applications: NonFerrous Metal, Thick Metal, Wood, Plastics, & Composites. [Read more]

Brand: Lenox Tools

Super Sawzall 3 5/8 Inch Reciprocating Saw Blade Pack Of 5 48005163 by Milwaukee

Super Sawzall 3 5/8 Inch Reciprocating Saw Blade Pack Of 5 48005163 by Milwaukee

$14.35  $11.30

Reciprocating saw blades bimetal metal cuttingsuper sawzall vinyl pouch teeth per inch=18 Length 35/8 inch card of 5 Matrix II high speed steel teeth containing 8 percent Cobalt to keep a sharper tooth edge longer. BiMetal design allows faster cutting, longer life blades that can bend without shattering. 1/2 in. Universal Tang fits all Sawzalls. Applications: Scroll Cutting Metal 1/8 in. [Read more]

Brand: Milwaukee

Makita 18 Volt LXT Lithium Ion Reciprocating Saw Kit BJR181 by Makita

Makita 18 Volt LXT Lithium Ion Reciprocating Saw Kit BJR181 by Makita

$465.19  $418.30

Cordless reciprocating saw kits 18 volt variable speed Variable speed motor combined with a 11/8 length stoke to provide faster cutting, toolless blade change system allows for faster blade installation and removal, large 2finger variable speed trigger for added convenience, two builtin LED lights illuminate the work area, retractable tool hook compact, ergonomic shape, soft grip, LXT LithiumIon battery with 16 firm holding contact terminals, 30minute rapid optimum charger communicates with the battery's builtin chip throughout the charging process to optimize battery life by actively controlling current, voltage and temperature, 30minute rapid optimum charger has a builtin fan to cool the battery to produce more lifetime work, charger earned the Energy Star label for meeting the strict energyefficient guidelines set by the EPA and DOE. Specs: 1 1/8 inches stroke length, max cutting depth: pipe5 1/8 inches, wood 10 inches, strokes/min 02,900SPM, 18V LXT LithiumIon battery, 19 5/8 inche [Read more]

Brand: Makita

10 Amp Electric Reciprocating Saw CR13V by Hitachi

10 Amp Electric Reciprocating Saw CR13V by Hitachi

$137.29  $123.10

Reciprocating saws 11/8 inch10 ampvs Lightweight saw with variable speed, blade changing system, quick and easy requiring no tools and only one hand, reversible blade, mountable up or down, Dshaped handle, trigger, oversized to improve manageability, adjustable pivot foot, dust and water resistant, triple sealed construction. Specs: no load speed 02,800 SPM, 1 1/8 inches stroke length, keyless blade clamp, 17 1/8 inches long, weighs 7.3 pounds Includes: heavy duty carrying case, all purpose blade, hex bar wrench. [Read more]

Brand: Hitachi

Super Sawzall 6 Inch Reciprocating Saw Blade Pack Of 5 48005182 by Milwaukee

Super Sawzall 6 Inch Reciprocating Saw Blade Pack Of 5 48005182 by Milwaukee

$14.65  $10.80

Reciprocating saw blades bimetal metal cuttingsuper sawzall vinyl pouch teeth per inch=14 Length 6 inch card of 5 Matrix II high speed steel teeth containing 8 percent Cobalt to keep a sharper tooth edge longer. BiMetal design allows faster cutting, longer life blades that can bend without shattering. 1/2 in. Universal Tang fits all Sawzalls. Applications: Cutting Metal 3/16 in. thru 1/4 in, Conduit, Tubing, Channels, Pipe, Rubber, & Fiber. [Read more]

Brand: Milwaukee

DeWalt 10 Amp Heavy Duty Reciprocating Saw Kit DW304PK by DeWalt

DeWalt 10 Amp Heavy Duty Reciprocating Saw Kit DW304PK by DeWalt

$129.59  $116.20

Reciprocating saws 11/8 inch10 ampvs Variable speed trigger allows user to control speed, 4position blade clamp allows for flush cutting and increased versatility, powerful motor designed for heavy duty applications, keyless lever action blade clamp for quick and easy blade changes. Specs: strokes/min 02,800SPM, 1 1/8 inches stroke length, keyless blade clamp lever, 4 position blade clamp, fixed adjustable shoe, variablespeed trigger, 17.5 inches long, weighs 7.0 pounds Includes: kit box, instruction manual. [Read more]

Brand: Dewalt

Blackstone Industries FB08593DB 93-1/2 X .025 X 1/8 in. Band Saw Blade

Blackstone Industries FB08593DB 93-1/2 X .025 X 1/8 in. Band Saw Blade

$15.10

For hard or soft wood plastic mild steel and non-ferrous metal (for machines with speed reduction) For all vertical stationary floor standing 2-wheel band saws. .025 x 1/8 in. wide TPI style:14 regular 93-1/2 in. length [Read more]

Brand: Blackstone Industries

Blackstone Industries FB10093DB 93-1/2-In. X .025-In. Band Saw Blade

Blackstone Industries FB10093DB 93-1/2-In. X .025-In. Band Saw Blade

$13.70

Features: For hard or soft wood, plastic, mild steel, and non-ferrous metal (for machines with speed reduction)For all vertical, stationary, floor standing 2-wheel band saws What's In The Box: Blackstone Industries FB10093DB 93-1/2-In. X .025-In. Band Saw Blade [Read more]

Brand: Blackstone Industries

Vermont American 31107 1/4-Inch X 57-Inch 6TPI Wood Cutting Band Saw Blade

Vermont American 31107 1/4-Inch X 57-Inch 6TPI Wood Cutting Band Saw Blade

$23.66

Features: Made to exacting standards, specially set and sharpened for clean, fast cuts Every blade is made of highest quality steel and is 100 percent inspected to assure maximum strength in the weld joint For fast cutting in all woods, plastics, and composites6 TPI1/4 inch width 57 inch length, .012 inch gauge Carded What's In The Box: Vermont American 31107 1/4-Inch X 57-Inch 6TPI Wood Cutting Band Saw Blade [Read more]

Brand: Vermont American

Blackstone BM82164BL 64-1/2-In. X 1/2-In. 10/14TPI Band Saw Blade

Blackstone BM82164BL 64-1/2-In. X 1/2-In. 10/14TPI Band Saw Blade

$31.52

Features: For popular 5-1/2 in and 4 in x 6 in horizontal band sawsVariable pitch teeth vary in size, set and gullet depth which brings teeth into the work at constantly changing angles for fast, smooth and quiet cuttingThe varying gullet sizes allow increased protection against tooth strippage when cutting on a wide range of materials and/or dimensions0.025 in. x 1/2 in. wideTPI style: 10/14 variable pitch64-1/2 in. length What's In The Box: Blackstone BM82164BL 64-1/2-In. X 1/2-In. 10/14TPI Band Saw Blade [Read more]

Brand: Blackstone Industries

Blackstone Industries HB71864BL 64-1/2 X .025 X 1/2 in. Horizontal Band Saw Blad

Blackstone Industries HB71864BL 64-1/2 X .025 X 1/2 in. Horizontal Band Saw Blad

$11.99

For popular 5-1/2 in and 4 in x 6 in horizontal band saws Hard Back blades permit greater tension, improved blade rigidity and straighter, more accurate cuts Wavy Tooth Style has three teeth with varying sets to the right followed by one straight tooth and three teeth with varying sets to the left Because three teeth share the cutting and the set extends below the gullets, wavy set teeth are less likely to strip than raker set teeth .025 x 1/2 in. wide TPI style: 18 wavy 64-1/2 in. length [Read more]

Brand: Blackstone Industries

Blackstone BM82264BL 64-1/2-In. X 1/2 in. Horizontal Band Saw Blade

Blackstone BM82264BL 64-1/2-In. X 1/2 in. Horizontal Band Saw Blade

$31.52

Features: For popular 5-1/2 in and 4 in x 6 in horizontal band sawsVariable pitch teeth vary in size, set and gullet depth which brings teeth into the work at constantly changing angles for fast, smooth and quiet cuttingThe varying gullet sizes allow increased protection against tooth strippage when cutting on a wide range of materials and/or dimensions.025 in. x 1/2 in. wideTPI style: 14/18 variable pitch64-1/2 in. length What's In The Box: Blackstone BM82264BL 64-1/2-In. X 1/2 in. Horizontal Band Saw Blade [Read more]

Brand: Blackstone Industries

Vermont American 31142 1/8-inch x 59-1/1-inch Scroll Cutting Band Saw Blade

Vermont American 31142 1/8-inch x 59-1/1-inch Scroll Cutting Band Saw Blade

$24.04

Band saw blade Recommended for fine scroll cutting in plywood, thin veneer, plastics and composite material 1/4" minimum radius .012" gauge 15 tpi 1/8" width 59-1/2" blade length Carded [Read more]

Brand: Vermont American

Blackstone HB71764BL 64-1/2-In. X 1/2-In. Wavy Tooth Horizontal Band Saw Blade

Blackstone HB71764BL 64-1/2-In. X 1/2-In. Wavy Tooth Horizontal Band Saw Blade

$11.99

Features: For popular 5-1/2-in. and 4-in. x 6-in. horizontal band sawsHard Back blades permit greater tension, improved blade rigidity and straighter, more accurate cutsWavy tooth style has three teeth with varying sets to the right followed by one straight tooth and three teeth with varying sets to the leftBecause three teeth share the cutting and the set extends below the gullets, wavy set teeth are less likely to strip than raker set teeth.025-in. x 1/2-in. wideTPI style: 14 wavy64-1/2-in. length What's In The Box: Blackstone HB71764BL 64-1/2-In. X 1/2-In. Wavy Tooth Horizontal Band Saw Blade [Read more]

Brand: Blackstone Industries

Vermont American 31147 1/4-inch x 59-1/2-inch Wood Cutting Band Saw Blade

Vermont American 31147 1/4-inch x 59-1/2-inch Wood Cutting Band Saw Blade

$23.69

Made of highest quality steel and is 100% inspected For general purpose woodcutting 6 tpi 1/4" width .012" gauge Carded 31147: 59-1/2" length [Read more]

Brand: Vermont American

Blackstone Industries FB23193DB 93-1/2 X .025 X 3 in. Hook Band Saw Blade

Blackstone Industries FB23193DB 93-1/2 X .025 X 3 in. Hook Band Saw Blade

$13.84

For hard or soft wood, plastic, mild steel and non-ferrous metal (for machines with speed reduction) For all vertical, stationary, floor standing 2-wheel band saws [Read more]

Brand: Blackstone Industries

Rockwell RK7453 9-inch Band Saw, 2.5 Amp w 59-1/2-inch Blade and Work Light

Rockwell RK7453 9-inch Band Saw, 2.5 Amp w 59-1/2-inch Blade and Work Light

$188.89

The Rockwell 9-Inch Band Saw with Work Light is a powerful bench-top band saw with a 2.5 Amp motor and a large 11-13/16-inch squared ribbed aluminum table. With a table tilting adjustment ranging from 0 to 45-degrees and a blade guide adjustment for custom depth settings this Bench Top Band Saw is extremely versatile. Features: Lightweight and easy to transport, weighing under 20-pounds Table tilts for bevel cuts from 0 to 45-degrees Reinforced cast aluminum table top for extra durability Blade quick tension adjustment Flexible work light illuminates the cutting area What's In The Box: Rockwell 9-Inch Band Saw 59-1/2-Inch Bandsaw Blade Work Light Parallel Guide Miter Gauge Hex Key [Read more]

Brand: Rockwell

Bosch BSH180B 18-Volt Li-Ion Compact Band Saw - Bare Tool

Bosch BSH180B 18-Volt Li-Ion Compact Band Saw - Bare Tool

$194.92

The Bosch BSH180B is a Bare 18-Volt Li-Ion Compact Band Saw. The new Bosch 18-Volt cordless compact band saw is up to 60-percent lighter that deep cut saws and up to 40-percent more compact. Its cutting capacity of 2-1/2-Inch by 2-1/2-Inch is ideal for the most common materials that electricians, plumbers and contractors work with. The flexible power system allows you to choose from a fat pack or slim pack battery. Features: Best-in-class compact size: up to 60-percent lighter than deep cut saws and up to 40-percent more compactIntegrated LED work light illuminates the cut line in dark areas2-1/2-Inch by 2-1/2-Inch cutting capacityRugged aluminum base: lightweight for easy portability; withstands tough jobsite conditionsElectronic Cell Protection (ECP): protects the battery from overload, overheat and deep dischargeBare tool, battery and charger sold separately What's In the Box: Bosch BSH180B 18-Volt Li-Ion Compact Band Saw - Bare ToolBattery NOT Included [Read more]

Brand: Bosch

Black Bull MBS45 4.5 Inch Metal Cutting Band Saw

Black Bull MBS45 4.5 Inch Metal Cutting Band Saw

$565.52

The Black Bull 4.5 Inch Metal Cutting Band Saw is small in size but big on power. Ideal to have on hand for cutting brass, aluminum rugged alloy, rebar, fencing, or steel tools. A must have tool for welders and handymen on the farm or in the shop. The saw head converts to cut both horizontally and vertically, or use the miter gauge for angle cutting 90 to 45 degrees. A 6 x 8 work table makes cutting smaller objects easier, or use the self-cut by laying the saw blade on the item and let gravity do the work. This Band Saw has a cutting capacity of 4.5 inches round or 4 x 6 inches rectangular, with a 4 by 5 inch adjustable vise. Safety features include a full blade guard, a locking pin that keeps the power button off, and a locking pin that keeps the saw head down for storage and transport. Two wheels and a handle make the Band Saw easy to move and maneuver. Cuts brass, aluminum rugged alloy and steel tools, miter gauge for angle cutting 45 to 90 degree anglesConverts for horizontal and vertical use, full blade guard, spring loaded motor mount3 blade speeds: 60 / 120 / 220 fpm, cutting capacity: 4.5 inch round or 4 x 6 inch rectangularAdjustable vise size: 4 x 5 inches, 3/4 Hp motor/single phase, 120v / 60 Hz / 500 watts / 5.4 ampsOverall size: 36 inches l x 16 inches w x 38 inches h (closed), 36 inches l x 16 inches w x 54 inches h (open), weight: 124.5 lbs, assembly required [Read more]

Brand: Black Bull

Powermatic 1791800 PM1800 18-inch 5-Horsepower Single-Phase Band Saw

Powermatic 1791800 PM1800 18-inch 5-Horsepower Single-Phase Band Saw

$4,794.99

The new Powermatic 1791800 PM1800 18-inch Band Saw, 5HP, Single Phase is a part of the new breed of high performance products from Powermatic. The PM1800 is designed with an enormous 18-inch resaw, multi-step blade tension, precision blade guides, and a 5HP motor hungry for hardwoods. This powerhouse comes standard with all the extra features you've come to expect from Powermatic. Features: Blade tension lever has full tension, partial tension, and release settings for easy blade changes and trackingMicro-adjustable, virtually tool-less bearing guide system gives close blade control while reducing frictionHeavy duty T-style rip fence has adjustable aluminum resaw fenceDual 4-inch exhaust ports for effective dust and chip removalMagnetic starter with power indicator lamp and jumbo stop18-inch resaw, and 18-inch blade to column capacity2-inch diameter solid steel pin for resaw workLarge 24-inch x 24-inch cast iron tableAdjustable miter gauge with stopsWhat's In The Box: Powermatic 1791800 PM1800 18-inch Band Saw, 5HP, Single Phase [Read more]

Brand: Powermatic

Jet 709290 Raker Tooth Band Saw Blade

Jet 709290 Raker Tooth Band Saw Blade

$8.90

Jet 709290 Raker Tooth Band Saw Blade [Read more]

Brand: Jet

Steel City 50130 14-inch Granite Deluxe Band Saw

Steel City 50130 14-inch Granite Deluxe Band Saw

$1,176.92

The Steel City 50130 14-inch Granite Deluxe Band Saw uses an exclusive solid granite table that provides unsurpassed rust resistance and flatness, as well as a granite lower wheel to create a flywheel effect for even the toughest cutting operations. The Steel City 50130 has a powerful 1-1/2 HP dual capacitor motor to provide plenty of power for your sawing needs. With a rack and pinion blade guide adjustment and a quick release blade tension lever, the Steel City 50130 allows for quick and repeated adjustments. Features: Eccentric adjustable ball bearing guides require no tools for the precision roller bearing guides, you get quick and accurate set-ups when changing blade sizesLower Granite Wheel is dynamically balanced for vibration free cutting and gives you a fly wheel effect for even the toughest cutting operations4-inch dust port is integrated to provide a maximum extraction of dust chips, while brush minimizes sawdust build up on the lower wheelBuilt-In mobile base is integrated into the stand for excellent maneuverability and total portability without the added expenseLarge Granite Table is mounted on widely spaced trunnions for support of large workpieceHinged Wheel covers for fast blade changesWhat's In The Box: Steel City 50130 14-inch Granite Deluxe Band SawEccentric Adjustable Bearing GuidesQuick Release Blade Tension LeverLamp AttachmentMobile BaseFence RailsRip FenceWrenchesManual [Read more]

Brand: Steel City

Fig. 2 - Portable hacksawing machine - Sierra cortametales portátil



THE PORTABLE BAND SAWING MACHINE

The portable band sawing machine (Figure 2) or portable band saw is a lightweight, hand-held unit powered by an electric motor. The saw motor and gears rotate a solid steel band saw blade around two large wheel pulleys and through several saw blade guides at such an angle to give clearance to the workpiece being cut. The portable band saw can cut steel round stock to 3 3/8 inch diameter or steel rectangular stock 3 3/8-inch thick by 4 1/8 inch wide. The portable metal band sawing blades are 44 7/8 inches long and can have from 6 to 24 teeth per inch, providing a wide range of cutting capabilities. Single-speed band saw models are designed for softer metals, such as brass, aluminum, and mild steel. Two-speed and variable speed models can be switched to a low speed to cut harder metals, such as stainless steel or tungsten. The band saw blade is completely enclosed, using the motor housing as a blade guard, except for the exposed part of the blade that does the sawing. A hand grip and trigger switch are provided on one end of the saw and a knob grip is on the other end to provide for maximum control while sawing.

To start sawing, make sure that the material to be cut is held very securely in the vise to avoid excessive vibration.

Select the appropriate blade for the material to be cut and mount the blade securely into the portable band saw in accordance with the manufacturer's instructions. Take hold of the front knob grip handle and rear hand grip handle and squeeze the trigger switch to start the saw blade in motion. Set the speed appropriately if operating a two-speed or variable speed model. Gently lower the portable band saw onto the workpiece, being careful to use the weight of the machine as pressure to cut. If the operator uses additional pressure on the workpiece, the saw blade will slow down and reduce the cutting efficiency. Hold the machine steady and the saw blade straight to avoid twisting or breaking the blade. At the completion of the cut, do not allow the saw to fall onto the workpiece. Maintain hand control of the machine, release the trigger switch, and allow the blade to stop before setting down the saw. Never use a liquid coolant with the portable band sawing machine as this could damage the saw guide bearings or rubber pulleys. Lubricate and service each saw as specified in the manufacturer's instructions.

THE PORTABLE RECIPROCATING SAW

The portable reciprocating saw (Figure 3) is a handheld lightweight machine tool that can be electrically or pneumatically powered, depending on the model selected. The saw motor and gearing cause a single knife-like blade to move rapidly in and out, sawing across a workpiece as hand pressure is applied. The saw may be a one-speed model or two speed model. The one-speed model operates at high speed only and is used for cutting soft materials like wood or sheet rock. The two-speed models have a switch that can move the speed from high speed to low speed, so that harder materials, such as metal pipes and steel sheets, can be cut.

The portable reciprocating saw, with the proper blade installed, can cut through steel stock up to 1 inch square or steel pipe up to 4 inches in diameter. An enclosed hand grip handle with trigger switch is provided at one end of the saw and another hand grip is toward the front of the saw, near the blade, to provide for maximum control while sawing. The blade freely protrudes from an angled work rest that is attached to the motor housing. There is no blade guard, so care must be exercised at all times.



LA MÁQUINA ASERRADORA DE CINTA PORTÁTIL

La máquina de sierra de cinta (figura 2) o máquina aserradora de cinta portátil es una unidad liviana, manual accionada por un motor eléctrico. El motor y los engranajes de la sierra hacen girar una hoja de sierra de cinta sólida de acero alrededor de dos poleas ruedas grandes y a través de varias guías de hoja de sierra a un ángulo tal que permita el espacio necesario al objeto que es cortado. La máquina aserradora de cinta portátil puede cortar material redondo de acero de hasta de 3 3/8 pulgada de diámetro o material rectangular de acero 3 3/8 pulgadas de espesor por 4 1/8 pulgada de ancho. Las hojas de sierra de metal de la máquina portátil tienen 44 7/8 pulgadas de largo y pueden tener desde 6 hasta 24 dientes por pulgada, proporcionando una amplia gama de capacidades de corte. Los modelos de máquinas de aserrar de velocidad única están diseñados para metales más blandos, tales como latón, aluminio, y acero blando. Los modelos de dos velocidades y de velocidad variable se pueden cambiar a baja velocidad para cortar metales más duros, tales como acero inoxidable o tungsteno. La hoja de sierra de banda está totalmente oculta, usando el compartimento del motor como protector de hoja, a excepción de la parte expuesta de la hoja que realiza el corte. Una manivela y un interruptor de encendido se encuentran en un extremo de la sierra y una perilla de agarre se encuentra en el otro extremo para proporcionar máximo control mientras se asierra.

Para comenzar a aserrar, cerciórese de que el material que se cortará está ajustado muy firmemente en la morsa para evitar una vibración excesiva.

Seleccione la hoja apropiada para el material que será cortado y coloque la hoja con seguridad en la sierra portátil de banda de acuerdo con las instrucciones del fabricante. Tome la perilla de sujeción frontal y la manija posterior y presione el interruptor disparador para poner la hoja de sierra en movimiento. Fije la velocidad apropiadamente si opera un modelo de dos velocidades o de velocidad variable. Baje suavemente la sierra portátil de banda sobre el objeto, teniendo cuidado de utilizar el peso de la máquina como presión para cortar. Si el operador utiliza presión adicional sobre el objeto, la hoja de sierra se volverá más lenta y se reducirá la eficacia del corte. Sostenga la máquina firmemente y la hoja de sierra en forma recta para evitar torcer o romper la hoja. Al finalizar el corte, no permita que la sierra caiga sobre el objeto. Mantenga el control manual de la máquina, libere el interruptor de disparo, y permita que la hoja se detenga antes de apagar la sierra. Nunca utilice un líquido refrigerante con la sierra portátil de banda pues esto podría dañar los rodamientos de guía de la sierra o las poleas de goma. Lubrique y mantenga cada sierra según lo especificado en las instrucciones del fabricante.

LA SIERRA RECÍPROCA PORTÁTIL

La sierra recíproca portátil (también conocida como sierra sable, sierra reciprocante, sierra de movimiento alternativo, sierra caladora, sierra alternativa , etc.) (Figura 3) es una máquina herramienta liviana manual que se puede accionar eléctrica o neumáticamente, dependiendo del modelo seleccionado. El motor y el engranaje de la sierra hacen que una sola lámina similar a un cuchillo se mueva rápidamente hacia adentro y fuera, aserrando a través de un objeto mientras que la presión manual es aplicada. La sierra puede ser un modelo de velocidad única o un modelo de dos velocidades. El modelo de velocidad única funciona a alta velocidad solamente y se utiliza para cortar materiales blandos como madera o planchas de roca. Los modelos de dos velocidades tienen un interruptor que pueden cambiar la velocidad desde velocidad alta a baja velocidad, de modo que materiales más duros, tales como tubos de metal y hojas de acero, puedan ser cortados.

La sierra recíproca portátil, con la hoja apropiada instalada, puede cortar a través material de acero de hasta 1 pulgada cuadrada o caños de acero de hasta 4 pulgadas de diámetro. Una manija con el interruptor de disparo incluido se encuentra en un extremo de la sierra y otra manija para sujeción está hacia la parte frontal de la sierra, cerca de la hoja, para proporcionar control máximo mientras se asierra. La lámina resalta libremente de un portapiezas anguloso que se fija al compartimento del motor. No hay protector de lámina, así que se debe tener cuidado siempre.



Fig. 3 - Portable reciprocating saw - Sierra recíproca portátil

To start sawing, ensure the material to be cut is held securely to avoid vibration that could break the saw blade. Select the right blade for the material to be cut and mount the blade into the blade clamp according to the manufacturer's instructions. Check the speed setting, get a firm grip on both handles, and squeeze the trigger switch. Guide the saw so that the work rest is against the workpiece and lower the saw until the blade starts cutting into the workpiece. Keep a firm grip through the saw cut and control the saw to avoid twisting or breaking the blade. After the cut is completed, maintain control of the saw and release the trigger switch. Allow the blade to come to a complete stop before laying the tool down. Periodically lubricate and service the portable reciprocating saw according to the manufacturer's instructions.



Para comenzar a aserrar, asegúrese de que el material que se cortará está ajustado con seguridad para evitar la vibración que podría romper la hoja de sierra. Seleccione la hoja correcta para el material que será cortado y coloque la hoja en la abrazadera de hoja siguiendo las instrucciones del fabricante. Compruebe el ajuste de la velocidad, asegure una presión firme en ambas manijas, y oprima el interruptor del disparador. Dirija la sierra de modo que el portapiezas esté contra el objeto y baje la sierra hasta que la hoja comience a cortar el objeto. Mantenga una presión firme durante el corte de la sierra y controle la sierra para evitar torcer o romper la hoja. Después de que se termine el corte, mantenga el control de la sierra y libere el interruptor del disparador. Permita que la hoja alcance a una parada completa antes de poner la herramienta abajo. Lubrique y mantenga periódicamente la sierra de recíproca portátil según las instrucciones del fabricante.
